Pressure washers are essential tools for a variety of cleaning tasks, from removing dirt and grime from sidewalks to washing cars and trucks. The spray gun is an integral part of a pressure washer, allowing the user to control the water flow and pressure. But have you ever wondered how a pressure washer spray gun works?

In this article, we will explore the inner workings of a pressure washer spray gun and what you might find if you were to tear one apart. By understanding how the spray gun functions, you can better maintain and troubleshoot any issues that may arise with your pressure washer.

Inside the housing of a pressure washer spray gun, you will typically find several key components. These include a trigger, valve, inlet and outlet connectors, and sometimes additional features such as adjustable pressure settings or safety locks. The trigger serves as the main control, allowing you to start and stop the water flow. The valve, often a spring-loaded mechanism, regulates the pressure of the water and prevents backflow.

When you pull the trigger of a pressure washer spray gun, you activate the valve, allowing water to flow from the inlet connector through the valve and out of the outlet connector. The force of the water passing through the spray gun creates the high-pressure spray that is a trademark of pressure washers. By releasing the trigger, you close the valve and stop the water flow.

Tearing apart a pressure washer spray gun can reveal even more fascinating components. You may find seals, o-rings, springs, and other small parts that contribute to the proper functioning of the spray gun. Getting a closer look at these components can help you understand how they interact and what may need attention if your spray gun is not working properly.
